5.0 INSTALLATION AND FIXING
2
EXT.SBB-HFF.--.M.A.0219.EN Issue: A
02.19
38
SBB-HFF
Danger - Warning
Handle the cutting kit with care, use all appropriate PPE to avoid injuries and accidents.
Tip
Sharp blades
Sharp blades
Remove the protection only after the kit has been secured to the machine.
ASSEMBLING
1) The Accessory Kit consists of a cutting kit and n.3 M3 screws including the washers and nuts.
2) The kit is supplied with shileds on the blades and tip.
3) It is mandatory to secure the cutting kit with all 3 screws supplied and use the bores provided on the Hopper
(items 1, 2, 3, g.1).
