03.11
1
TOR.119.--.T.4L Rev.A1
VAR
DIMENSIONS OF DIVERTER VALVE WITH PNEUMATIC ACTUATOR
ABMESSUNGEN DER WEICHE MIT PNEUMATISCHEM ANTRIEB
DIMENSIONS VANNES DEVIATRICE AVEC ACTUATEUR PNEUMATIQUE
DIMENSIONI DEVIATORE CON ATTUATORE PNEUMATICO
07
Type C G H M
80
333
460 106
293
100
340 300
125
405
520 123
365
150
422 382
175
473
750 148
433
200
489 449
G
C
H
Micro switch
cable gland
M
