PGT
®
120.COM Art.Nr. 7100.PGT120.COM
11 / 17 2016-09-07
Error no.
Sense
1
Resistance wrist strap to low
2
Resistance wrist strap to high
4
Resistance left shoe to low
8
Resistance left shoe to high
16
Resistance right shoe to low
32
Resistance right shoe to high
64
Voltage to low or to high
128
tbd
-10
contact electrode was released to early
If several errors occur the error numbers are added.
Example 1:
Data :
<STX>RHG 2671<ETX><CR><LF>
<STX>ERG OK<ETX><CR><LF>
Sense :
Resistance wrist strap 2,671 MOhm,
Test result OK
Example 2:
Data :
<STX>RSL OVR<ETX><CR><LF>
<STX>RSR 12415<ETX><CR><LF>
<STX>ERG 8<ETX><CR><LF>
Sense :
Resistance left shoe exceeds the measurment range
Resistance right shoe is 12,415 MOhm
Test faild with error no. 8 (Resistance left shoe to high)
