Warmbier PGT 120 - Data Output via RS232

PGT
®
120.COM Art.Nr. 7100.PGT120.COM
10 / 17 2016-09-07
6 Data output via RS232
Measured values and test result were output via serial port.
No.
Sense
Start
Prefix
Data
End
1
value
footwear in
series
<STX>
RSG
<SP>
value in kOhm
(UNR  under range)
(OVR  over range)
<ETX>
<CR> <LF>
2
value
wrist strap
<STX>
RHG
<SP>
value in kOhm
(UNR  under range)
(OVR  over range)
<ETX>
<CR> <LF>
3
value
left shoe
<STX>
RSL
<SP>
value in kOhm
(UNR  under range)
(OVR  over range)
<ETX>
<CR> <LF>
4
value
right shoe
<STX>
RSR
<SP>
value in kOhm
(UNR  under range)
(OVR  over range)
<ETX>
<CR> <LF>
5
test OK
<STX>
ERG
<SP>
OK
<ETX>
<CR> <LF>
6
Test failed
<STX>
ERG
<SP>
Error no.
<ETX>
<CR> <LF>
The order of data of one test is the same as above numbers, but not all data are
output by one test.
<STX> = control character "Start of Text" (ASCII 002)
<ETX> = control character "End of Text" (ASCII 003)
<CR> = control character "Carriage Return" (ASCII 013)
<LF> = control character "Line Feed" (ASCII 010)
<SP> = Space (ASCII 032)
