WarmFlow 70/90 Installation & Servicing Manual

1.6 Components 50/90 Front Servicing Boiler
INSULATION
RETAINER
BOILER TEST POINT
EXTERNAL DOOR
INSULATION
BURNER RESET BUTTON/
LOCK OUT LAMP
RDB
BURNER
OPTIONAL AIR
INTAKE SPIGOT
SIDE
CASING
FLUE RING
TOP CASING
THERMOSTAT
POCKET
WHITEBIRD
THERMOSTAT
GOLDBIRD
CONTROL PANEL
BAFFLES
INSULATION SHIELD
DOOR INSULATION
DOOR GASKET
SERVICE DOOR
BOILER CONTROL
THERMOSTAT
LIMIT THERMOSTAT
RESET BUTTON COVER
SERVICING DOOR
1" BSP DRAIN VALVE
CONNECTION
BAFFLES
4 No 3" BSP CONNECTIONS
FIREBRICK REAR
AND BOTTOM
BOILER CASING
2 No
1
/ 2 " BSP CONNECTIONS
FLUE TOP LID
1.7 Components – 300, 400 and 500 BB Industrial Boilers (x 1000 Btu/hr)
Page 4
