Warmhaus EWA 28 - INSTALLATION PERSONNEL SECTION

7
warmhaus.com
2. INSTALLATION PERSONNEL SECTION
I. Installaton Scheme (Fgure 1)
II. User's Gude (Fgure 2)
III. Connecton Accessores (Fgure 3)
a. 1 throttle screw (nstalled at flue output).
b. 2 hanger screws
c. 2 Dowels
IV. Hanger Plate (Fgure 4)
V. Exhaust Gas Flue Set (Fgure 5)
Fgure 1 Installaton scheme
Fgure 4 Hanger Plate
Fgure 3 Connecton accessores
Fgure 2 User's Gude
Fgure 5 Exhaust gas flue set
471
1000
GAS
G3/4" G3/4"G3/4"
80 mm
65 mm
65 mm 64 mm
725 mm
592 mm
422 mm
G1/2"G1/2"
75 mm
73 mm
Ø110 mm
114 mm
(OPTIONAL)
Ewa
Priwa ERP / Priwa ERP Plus
Priwa / Priwa Plus
Enerwa / Enerwa Plus
150.11.606.000028
Do not leave packng materals (plastc, nylon, bags, etc.) at places
to be reached by chldren for preventng any dangers for health.
2.1. CONTENTS OF PACKING BOX
Warmhaus s sold as two boxes wth comb and flue set. Comb box contans below lsted materals and small box contans exhaust gas flue ppes.
