PARTS LIST
Part Number Qty Description
A1 1 BUMPER SHELL
A2 1 FAIRLEAD PLATE
A3 1 UPPER BUMPER MOUNT
A4 1 SKID PLATE
A5 1 LIGHT BRACKET
B1 19 M8 X 25MM HEX HEAD BOLT
B2 28 FLAT WASHER
B3 11 M8 LOCK NUT
B4 2 PLASTIC WASHER
A1
A2
B1
B2
B3
A3
A4
B4
A5
INSTALLATION INSTRUCTIONS
Figure 1
