Warn 90930 - Installation Preparation; Pre-Installation Cautions and Notices; Before You Begin: Battery Disconnection; Torque Specifications

PAGE 2 90925A0
Notice
Equipment Damage
  Always refer to the Installation and Specication Guide, supplied in the winch kit, for all wiring schematics and specic details
on how to wire this WARN product to your vehicle.
Read installation and operating instructions thoroughly.
BEFORE YOU BEGIN
Before you begin disconnect the positive battery lead from the battery.
Caution
Moving Parts Entanglement Hazard
Failure to observe these instructions could lead to minor or moderate injury.
 Always take time to fully read and understand the installation and Operations Guide included with this product.
Never operate this product if you are under 16 years of age.
Never operate this product when under the inuence of drugs, alcohol or medications.
Read installation and operating instructions thoroughly.
TORQUE SPECIFICATIONS
1/4, 6MM 8 lb. ft. (10.8 N-m)
5/16, 8MM 17 lb. ft. (12.5 N-m)
3/8, 10MM 30 lb. ft. (40.7 N-m)
7/16, 11MM 50 lb. ft. (67.8 N-m)
1/2, 12MM 75 lb. ft. (101.7 N-m)
TOOLS REQUIRED
- Metric Socket Set
- #27 Torx screwdriver
- Metric Wrench Set
- Socket Driver
TABLE OF CONTENTS
Torque Specications page 2
Tools Required page 2
Parts List page 3
Installation page 4-6
Maintenance/Care page 7
