s1fmdl1sm-REV1207 Model S1F Metallic Page 5
Dimensions in Millimeters
Dimensional Tolerance:± 3mm
Pump Shown
With 530-028-550
Integral Muffler
Both Suction And
Discharge Ports Are
Available With
1" BSP Tapered Connection
Discharge Port
1" NPT
Suction Port
1" NPT
Air Inlet
1/2" NPT
Integral Muffler
1" NPT Exhaust Port
For Optional Muffler
Styles Or Piping Exhaust
Air In Submerged
Applications
Metric Dimensions: S1F Metallic
Dimension
A
B C D E F
Encapsulated
Muffler
264
264
Pulse Output
Kit
Aluminum
301 28 8 158 323
304 31 11 161 326
Stainless
Steel
Mesh
Muffler
330
Sound
Dampening
Muffler
330
Metal
Muffler
319
