WARRIOR WEP8001ST User Manual

ASSEMBLY
11
ATTACHING THE AUXILIARY HANDLE (See Figure 5.)
• Press the auxiliary handle onto the power head shaft so that the handle is angled toward the rear
handle that allows for comfortable operation.
• Slide the bolts through the holes in the auxiliary handle, and tighten them securely with a Phillips
Head screwdriver (not included).
LINE TRIMMING CUT-OFF BLADE (See Figure 6.)
The trimmer is equipped with a line trimming cut-off blade on the guard. Replace the string when
trimming efficiency diminishes. This will maintain best performance.
ATTACHING A SHOULDER HANRNESS (See Figure. 7)
• Rotate the harness holder to the upward position.
• Hook a shoulder harness to the harness holder.
CUTTING OFF BLADE
Fig.6
Hardness holder
Fig.7
Fig. 5
