19.3 Engine components

Fig 19-4 Turbocharger (DAAE049544A)

Weight

complete

Weight

rotor block cartridge

GFEDCBATC type

1960465DN6005307918155409462003TPL 71C

3660815DN800690110090264113422301TPL 76C

6L and 12V46F are equipped with TPL 71C.

7L, 8L, 9L, 14V and 16V46F are equipped with TPL 76C.

Dimensions in mm. Weight in kg.

Fig 19-5 Charge air cooler inserts (DAAR013169)

WeightEDCEngine type

77065066019506L46F

96097086019507-9L46F

13508101115140712V46F

14308201115160714V46F

14308201115160716V46F

Dimensions in mm. Weight in kg.

19-4 Wärtsilä 46F Product Guide - a19 - 1 December 2017

Wärtsilä 46F Product Guide19. Transport Dimensions and Weights
