1.4 Dimensions and weights
1.4.1 Main engines
Fig 1-1 Main engine dimensions (DAAF336230)
LE4LE2HE3HE4WE1*WE1HE1*HE1LE1LE1*Engine
35035601496650311331133205320561146175W8V31
35042001496650311331133205320567546813W10V31
Weight
ton**
WE2WE3LE5LE5*WE6WE6*LE3LE3*WESEngine
56.71650115350050067-67167516751582W8V31
621650115350050067-67167516751585W10V31
Total length of engineLE1
Height from the crankshaft centerline to the highest pointHE1
Total width of the engineWE1
Height from the crankshaft centerline to the engine feetsHE4
Dimension from the crankshaft centerline to the bottom of the oil sump, when shallow oil
sump
HE3
Length of the engine blockLE2
Dimension from the end of the block to the end of the crankshaftLE4
Width of the oil sumpWE3
Width of the engine block at the engine feetWE2
Dimension from the center of the crankshaft to the outermost point of the engineWE5
Dimension from the engine block to the outermost point in turbocharger endLE3
Dimension from the center of the crankshaft to the centre of the exhaust outletWE6
Dimension from the end of the engine block to the centre of the exhaust gas outletLE5
* Turbocharger at flywheel end
** Weight with liquids (wet sump) but without flywheel
All dimensions in mm.
Wärtsilä 31 Product Guide - a1 - 18 October 2016 1-3
1. Main Data and OutputsWärtsilä 31 Product Guide
