Wascomat EX677 - Component Diagrams and Parts List

23
Machine presentation
6562
11
18
17
13
14
12
16
15
2
1
5
4
3
2
8
7
6
9
10
1. Detergent drawer
2. Water inlet valves
3, Power supply
4. I/O-board
5. Rear electrical module
6. Motor control
7. Outer drum
8. Coil spring (not SU- and W-model)
9. Motor
10. Shock absorber (not SU- and W-model)
11. Avloppsventil
12. Support
13. Door
14. Door lock
15. Program knob
16. Display
17. Control panel
18. Program unit
EX - model shown
