Water Ace RC10 CONVERTIBLE 1 HP User Manual (English)

Questions and Answers:

P
Paul MuellerAug 9, 2025
What to do if my Water Ace RC10 CONVERTIBLE 1 HP Water Pump won't shut off?
- L
  Larry EdwardsAug 9, 2025
  If your Water Ace Water Pump delivers water but won't shut off, several issues could be the cause. The impeller neck might be worn and needs replacement, or the pressure switch could be defective and require replacement. Try repositioning the O-ring seal. Also, the tank precharge pressure might be too high; adjust it to be 1–2 pounds less than the switch turn-on setting. It's also worth monitoring the water level during operation.
P
Priscilla PalmerAug 15, 2025
Why does my Water Ace Water Pump stop pumping after a while?
- S
  Stephen McmahonAug 15, 2025
  If your Water Ace Water Pump delivers water for a while and then stops, it could be due to a low well water level. Use a water-level tester while the pump is running to check this. Also, clear any blockages in the venturi tube, nozzle, or impeller parts, and try adjusting the regulator setting.
M
Mark ChapmanAug 21, 2025
What to do if the pressure switch on my Water Ace RC10 CONVERTIBLE 1 HP cycles rapidly?
- L
  lwilliamsAug 22, 2025
  If the pressure switch on your Water Ace Water Pump turns on and off every few seconds, the galvanized storage tank may be waterlogged; in this case, service or replace the tank. Alternatively, a leaky foot valve could be the issue, requiring repair or replacement. You can also try adjusting the tank pressure.
B
barrettkevinAug 27, 2025
Why is my Water Ace Water Pump not delivering the rated capacity?
- J
  Justin ParrishAug 27, 2025
  If your Water Ace Water Pump isn't delivering its rated capacity, start by clearing any blockages in the venturi or nozzle. Replace the pressure gauge if it's faulty. Adjust the operating pressure as needed. Check the well water level using a water-level tester while the pump runs. Reposition the diffuser O-ring seal. Ensure the ejector is within 10 feet of the pumping level to correct oversubmergence, and adjust the ejector size and depth setting if necessary.
S
Sarah SmithSep 2, 2025
Why does my Water Ace RC10 CONVERTIBLE 1 HP Water Pump motor overheat and shut off?
- D
  daniel68Sep 2, 2025
  If the motor of your Water Ace Water Pump overheats and shuts off, the motor voltage might not match the power supply voltage. Also check for the impeller rubbing against the pump case.

Water Ace RC10 CONVERTIBLE 1 HP Specifications

General

Brand	Water Ace
Model	RC10 CONVERTIBLE 1 HP
Category	Water Pump
Language	English

Summary

Important Pre-Installation Instructions

Determining Your Well Depth

Learn how to accurately measure the depth of your well to ensure proper pump selection and operation.

Pump Selection and Preparation

Pump Capacities and Voltage Selection

Understand pump performance charts and how to select the correct voltage for your pump.

Wiring and Piping Guidelines

Essential instructions for correctly wiring your pump and preparing the piping system.

Shallow Well Pump Installation

Shallow Well Pump Materials and Tools

Lists required materials and tools for installing a shallow well pump system.

Priming Shallow Well Jet Pumps

Step-by-step guide on how to properly prime shallow well jet pumps for correct operation.

Well Point Pump Installation Guide

Instructions for installing a pump using a well point system, covering materials and steps.

Deep Well Pump Installation

Materials for Deep Well RC5/RC10 Pumps

Lists necessary materials for installing the RC5 and RC10 deep well convertible pumps.

Deep Well Packer Pump Installation

Guide for installing deep well pumps using a packer system in 2" diameter cased wells.

Packer Pump Materials and Assembly

Details the materials and assembly steps for deep well packer pump installations.

Alternate Packer/Pump Connection

Instructions for an alternative method to connect the packer well adapter to the pump.

Troubleshooting Pump Issues

Pump Disassembly and Repair

Pump Repair Kit Identification

Identifies specific repair kits for RTS5, RTS7, RTS10, and RC5 pumps by model and kit number.

Limited Warranty Information
