Shown with R5W-1

R5W1830

WATER ACE PUMP COMPANY

|

1101 MYERS PARKWAY

|

ASHLAND, OHIO 44805-1969 (USA ONLY)

CONSUMER HOT-LINE: 1-800-942-3343

Monday–Friday 7 AM to 5 PM EST

www.waterace.com

INSTALLATION MANUAL Pgs. 2–5

SUBMERSIBLE SEWAGE PUMPS AND BASIN

POMPES D’ÉGOUT SUBMERSIBLES AVEC BASE

MANUEL D’INSTALLATION Pgs. 6–9

MANUAL DE INSTALACIÓN Pgs. 10–13

BOMBA DE AGUA DE DRENAJE SUMERGIBLE Y DEPÓSITO

R5W-1

R7W

23833A602 (Rev. 3/5/08)

5794 0308

Table of Contents

Questions and Answers

J
James PhillipsAug 4, 2025
Why does my Water Ace R7W Water Pump run but not deliver water?
- R
  Rhonda MyersAug 4, 2025
  Your Water Ace Water Pump might run but not deliver water for several reasons. The check valve could be installed backward; make sure the arrow on the valve points in the direction of flow. The discharge shut-off valve, if you're using one, might be closed, so check that it's open. The pump could be air-locked; try starting and stopping it several times by plugging and unplugging the cord. The impeller or volute openings could be clogged, or the inlet holes in the pump base could be obstructed; in either case, remove the pump and clean the affected parts. Finally, the vertical pumping distance might be too high; reduce the distance or resize the pump.
D
david64Aug 8, 2025
Why does my Water Ace R7W Water Pump fuse blow or the circuit breaker trip when the pump starts?
- T
  tyrone82Aug 9, 2025
  If the fuse blows or the circuit breaker trips when your Water Ace Water Pump starts, it could be due to several reasons. The pump impeller might be partially clogged with foreign matter, causing the motor to run slowly and overload; in this case, remove the pump and clean it. The fuse size or circuit breaker may be too small; ensure the fuse size is 15 amps. Also, the impeller or volute openings may be fully or partially clogged, requiring you to remove the pump and clean it.
K
Kristen FranklinAug 13, 2025
What to do if my Water Ace R7W Water Pump runs and pumps out sump, but does not stop?
- S
  Susan WhiteAug 13, 2025
  If your Water Ace Water Pump runs and pumps out the sump but doesn't stop, it could be that the float is stuck in the up position. Ensure the float operates freely in the basin. If that doesn't solve the issue, consider replacing the float switch.
A
Amber GriffinAug 18, 2025
What to do if my Water Ace R7W Water Pump does not run or hums?
- M
  Michelle RichardsAug 19, 2025
  If your Water Ace Water Pump doesn't run or hums, check the following: Ensure the line circuit breaker is on, or replace any blown or loose fuses. Confirm the water level in the sump reaches the turn-on level as indicated in the installation drawing. Check the pump cord connection in the receptacle to ensure it's making contact. Also, make sure the float operates freely in the basin. If all these are okay, the motor winding may be open.
C
Catherine ReedAug 25, 2025
Why Water Ace R7W motor runs for a short time, then stops?
- J
  Jeffery ScottAug 25, 2025
  If your Water Ace Water Pump motor runs for a short time and then stops, it could be due to a few reasons. The inlet holes in the pump base might be clogged, so remove the pump and clean the openings. The pump impeller could be partially clogged with foreign matter, causing the motor to run slowly and overload, so remove the pump and clean it. Also, the impeller or volute openings may be fully or partially clogged, requiring you to remove the pump and clean it.
B
brittney30Aug 29, 2025
How to fix Water Ace Water Pump that runs but delivers only a small amount of water?
- M
  Marc GarciaAug 29, 2025
  If your Water Ace Water Pump runs but delivers only a small amount of water, it could be air-locked; try starting and stopping it several times by plugging and unplugging the cord. The vertical pumping distance might be too high, so reduce the distance or resize the pump. The inlet holes in the pump base could be clogged, or the impeller or volute openings could be clogged. Also, the pump impeller might be partially clogged with foreign matter, causing the motor to run slow and overload. In any of these clogging cases, remove the pump and clean the openings.

Summary

Important Instructions Before Installation

Piping Guidelines

Guidelines for using PVC, galvanized steel, or copper pipe for pump discharge.

Installation Preparation and Materials

Details on pump installation, including required materials and tools for proper setup.

Pump Installation Steps and Performance Data

Complete Pump Installation Procedure

Step-by-step guide for installing the submersible sewage pump.

Pump Performance Table

Table showing pumping capacity for different discharge heights and models.

Troubleshooting and Pump Returns

Troubleshooting Checklist

Common pump problems and their possible causes and solutions.

Procedure for Returning a Defective Pump

Steps for safely returning a defective pump, including cleaning and packaging.

Limited Warranty Information

Warranty Terms and Conditions

Details on product warranty, exclusions, and purchaser's remedy for defects.

Water Ace R7W Specifications

General

Model	R7W
Voltage	115/230V
Housing Material	Cast Iron
Category	Water Pump
Outlet Size	1 inch
