CONSUMER HOT-LINE: 1-800-942-3343

Monday–Friday 7 AM to 5 PM EST

www.waterace.com

INSTALLATION MANUAL Pgs. 1–8

LAWN SPRINKLER PUMPS

POMPES POUR ARROSEURS DE PELOUSES

MANUEL D’INSTALLATION Pgs. 9–18

MANUAL DE INSTALACIÓN Pgs. 19–28

BOMBA DE ROCIADOR DE CÉSPED

WATER ACE PUMP COMPANY

|

1101 MYERS PARKWAY

|

ASHLAND, OHIO 44805-1969 (USA ONLY)

23833A308 (Rev. 11/7/05)

BAG #23834A002

R15L

1-1/2 HP

R10L

1 HP

R7L

3/4 HP

R25L

2-1/2 HP

R20L

2 HP

Table of Contents

Questions and Answers

R
Regina RichardsonAug 6, 2025
Why is my Water Ace Water Pump not delivering rated capacity?
- M
  Mandy AdamsAug 6, 2025
  If your Water Ace Water Pump isn't delivering its rated capacity, several factors could be at play. Start by checking that the suction pipe is submerged at least 3 feet below the water level and ensure the voltage of the pump matches the voltage of the power supply. Also, inspect the valve, suction piping, foot valve, or well point. Reduce the discharge system head, check for any leaks, and if the pump flow exceeds the well's capability, reduce the pump flow. Confirm all connections are airtight and that the suction pipe is 1-1/2".
B
Brandon RodriguezAug 12, 2025
What to do if Water Ace R7L Water Pump motor overheats?
- N
  nsheltonAug 12, 2025
  If your Water Ace Water Pump motor overheats and shuts off, make sure the motor voltage matches the power supply voltage. You may also want to check if the impeller is rubbing against the pump case. Refer to the Wire Size Guide on page 3.
S
Shane JosephAug 21, 2025
Why does my Water Ace Water Pump lose prime after starting?
- S
  Samuel DavisAug 21, 2025
  If your Water Ace Water Pump loses prime after starting, first make sure the suction pipe is at least 3 feet below the water level. Check for any leaks and ensure that the pump flow does not exceed the well's flow capability. Also, check that all connections are airtight.
D
Danielle StewartAug 27, 2025
Why is my Water Ace R7L so noisy?
- J
  Joy SullivanAug 27, 2025
  If your Water Ace Water Pump vibrates or is noisy, ensure that the pump foundation is sufficient. Also, check for a bent shaft, worn motor bearing, or a clogged impeller. Note that the well depth should not exceed the pump's capability.

Summary

IMPORTANT INSTRUCTIONS BEFORE INSTALLATION

FINDING THE DEPTH OF YOUR WELL

Guide to determine well depth for optimal pump operation, crucial for performance.

PIPING

Details on pipe material and ensuring airtight joints for proper pump function.

SPECIFICATIONS

FUSE;BREAKER & WIRE SELECTION GUIDE

Table detailing wire size, fuse/breaker recommendations based on pump model and voltage.

PUMP CAPACITIES

Performance data including discharge pressure, flow rates, and shut-off head for each pump model.

LAWN SPRINKLER PUMP INSTALLATION

General Materials

List of required materials for pump installation, including PVC components and tools.

Tools needed for all pump installations

Essential tools required for performing the pump installation process correctly.

WELL POINT PUMP INSTALLATION

MULTIPLE WELL POINTS

Guidance on connecting multiple well points for increased flow, maintaining equal distances.

DRAINING AND SERVICING OR FOR WINTER

Instructions for draining the pump and piping to prevent damage from freezing or for maintenance.

TROUBLESHOOTING CHECKLIST

PUMP DISASSEMBLY

Visual guide and steps for disassembling the pump for maintenance or repair.

REPAIR KITS

Information on available repair kits for diffusers, impellers, and general seal replacements.

LIMITED WARRANTY

Water Ace R7L Specifications

General

Housing Material	Cast Iron
Voltage	115V
Outlet Size	1 inch
Phase	Single Phase
Model	Water Ace R7L
