RC
RTS
CONSUMER HOT-LINE: 1-800-942-3343
Monday–Friday 7 AM to 5 PM EST
www.waterace.com
INSTALLATION MANUAL Pgs. 1–13
JET PUMPS
POMPES ACCÉLÉRATRICES
MANUEL D’INSTALLATION Pgs. 14–26
MANUAL DE INSTALACIÓN Pgs. 27–39
BOMBAS DE CHORRO
DEEP
WELL PUMP
SHALLOW
WELL PUMP
MODEL RTS5 1/2 HP
MODEL RTS7 3/4 HP
MODEL RTS10 1 HP
MODEL RC5 CONVERTIBLE 1/2 HP
MODEL RC10 CONVERTIBLE 1 HP
WATER ACE PUMP COMPANY
|
1101 MYERS PARKWAY
|
ASHLAND, OHIO 44805-1969 (USA ONLY)
23833A472 (Rev. 12/8/05)
BAG #23834A021

Questions and Answers

  • M
    mfosterAug 5, 2025
    What to do if my Water Ace RTS5 1/2 HP Water Pump won't shut off?
    • C
      chase11Aug 5, 2025
      If your Water Ace Water Pump delivers water but won't shut off, several issues could be the cause. The impeller neck might be worn and needs replacement, or the pressure switch could be defective and require replacement. Try repositioning the O-ring seal. Also, the tank precharge pressure might be too high; adjust it to be 1–2 pounds less than the switch turn-on setting. It's also worth monitoring the water level during operation.
  • J
    Jennifer MatthewsAug 11, 2025
    Why does my Water Ace Water Pump stop pumping after a while?
    • M
      Mr. Anthony SextonAug 11, 2025
      If your Water Ace Water Pump delivers water for a while and then stops, it could be due to a low well water level. Use a water-level tester while the pump is running to check this. Also, clear any blockages in the venturi tube, nozzle, or impeller parts, and try adjusting the regulator setting.
  • W
    woodsbrookeAug 17, 2025
    What to do if the pressure switch on my Water Ace RTS5 1/2 HP cycles rapidly?
    • E
      Elaine ClarkAug 17, 2025
      If the pressure switch on your Water Ace Water Pump turns on and off every few seconds, the galvanized storage tank may be waterlogged; in this case, service or replace the tank. Alternatively, a leaky foot valve could be the issue, requiring repair or replacement. You can also try adjusting the tank pressure.
  • E
    Elizabeth MorrisAug 23, 2025
    Why is my Water Ace RTS5 1/2 HP Water Pump not delivering the rated capacity?
    • W
      William GreeneAug 23, 2025
      If your Water Ace Water Pump isn't delivering its rated capacity, start by clearing any blockages in the venturi or nozzle. Replace the pressure gauge if it's faulty. Adjust the operating pressure as needed. Check the well water level using a water-level tester while the pump runs. Reposition the diffuser O-ring seal. Ensure the ejector is within 10 feet of the pumping level to correct oversubmergence, and adjust the ejector size and depth setting if necessary.
  • D
    Devin OlsenAug 29, 2025
    Why does my Water Ace Water Pump motor overheat and shut off?
    • B
      Bruce JonesAug 29, 2025
      If the motor of your Water Ace Water Pump overheats and shuts off, the motor voltage might not match the power supply voltage. Also check for the impeller rubbing against the pump case.

Summary

Important Instructions Before Installation

Process A. Knowing the Depth of Your Well

How to measure the depth of your well to select the correct pump.

Process B. Correctly Select Your Pump

IMPORTANT: SELECT CORRECT VOLTAGE

Ensure correct voltage selection for pump operation and warranty.

WIRING YOUR PUMP

Step-by-step guide for properly wiring the pump motor.

PIPING

Instructions for connecting piping and ensuring all joints are airtight.

Process C. 1. Install a shallow well pump (RTS5, RTS7, RTS10)

DRAINING FOR SERVICING OR FOR WINTER

Draining the pump for maintenance or protection against freezing.

General Materials Required

List of necessary parts and materials for shallow well pump installation.

Tools needed for all pump installations

List of tools required for the pump installation process.

Process C. 2. Install a deep well pump (RC5, RC10)

DEEP WELL PUMP INSTALLATION (4 DIAMETER CASED WELL)

Specific installation steps for deep well pumps in cased wells.

General materials needed for either the RC5 or RC10 convertible pumps

List of materials for RC5 and RC10 convertible pumps.

In addition to General Materials for RC10 & RC5

Additional materials required for specific RC10 & RC5 models.

Process C. 3. Install a deep well pump with a packer

DEEP WELL PACKER PUMP INSTALLATION (2 DIAMETER CASED WELL)

Installation guide for deep well pumps with a packer in cased wells.

General Materials needed for either RC5 or RC10

Materials list for RC5/RC10 pumps used in packer installations.

In addition to General Materials for RC10 & RC5

Additional materials for RC10 & RC5 in packer installations.

ALTERNATE PACKER;PUMP CONNECTION FOR RC10 & RC5

Alternative connection method for RC10 & RC5 packer pump setups.

TROUBLESHOOTING CHECKLIST

PUMP DISASSEMBLY

REPAIR KITS FOR RTS5, RTS7, RTS10 & RC5 PUMPS

Part numbers for repair kits for specific pump models.

LIMITED WARRANTY

Exceptions to the Twelve (12) Month Warranty

Specific products with warranty periods differing from the standard twelve months.

General Terms and Conditions

Standard terms and conditions governing the product warranty.
