RC
RTS
CONSUMER HOT-LINE: 1-800-942-3343
Monday–Friday 7 AM to 5 PM EST
www.waterace.com
INSTALLATION MANUAL Pgs. 1–13
JET PUMPS
POMPES ACCÉLÉRATRICES
MANUEL D’INSTALLATION Pgs. 14–26
MANUAL DE INSTALACIÓN Pgs. 27–39
BOMBAS DE CHORRO
DEEP
WELL PUMP
SHALLOW
WELL PUMP
MODEL RTS5 1/2 HP
MODEL RTS7 3/4 HP
MODEL RTS10 1 HP
MODEL RC5 CONVERTIBLE 1/2 HP
MODEL RC10 CONVERTIBLE 1 HP
WATER ACE PUMP COMPANY
|
1101 MYERS PARKWAY
|
ASHLAND, OHIO 44805-1969 (USA ONLY)
23833A472 (Rev. 12/8/05)
BAG #23834A021

Questions and Answers

  • B
    Bobby CarpenterAug 9, 2025
    What to do if my Water Ace RTS7 3/4 HP won't shut off?
    • G
      gcookAug 10, 2025
      If your Water Ace Water Pump delivers water but won't shut off, several issues could be the cause. The impeller neck might be worn and needs replacement, or the pressure switch could be defective and require replacement. Try repositioning the O-ring seal. Also, the tank precharge pressure might be too high; adjust it to be 1–2 pounds less than the switch turn-on setting. It's also worth monitoring the water level during operation.
  • J
    Julia AlexanderAug 16, 2025
    Why does my Water Ace RTS7 3/4 HP stop pumping after a while?
    • G
      Glenn LewisAug 16, 2025
      If your Water Ace Water Pump delivers water for a while and then stops, it could be due to a low well water level. Use a water-level tester while the pump is running to check this. Also, clear any blockages in the venturi tube, nozzle, or impeller parts, and try adjusting the regulator setting.
  • J
    jennifercruzAug 22, 2025
    What to do if the pressure switch on my Water Ace RTS7 3/4 HP cycles rapidly?
    • M
      Michael CaldwellAug 22, 2025
      If the pressure switch on your Water Ace Water Pump turns on and off every few seconds, the galvanized storage tank may be waterlogged; in this case, service or replace the tank. Alternatively, a leaky foot valve could be the issue, requiring repair or replacement. You can also try adjusting the tank pressure.
  • D
    Daniel AustinAug 27, 2025
    Why is my Water Ace RTS7 3/4 HP not delivering the rated capacity?
    • C
      Carl HillAug 27, 2025
      If your Water Ace Water Pump isn't delivering its rated capacity, start by clearing any blockages in the venturi or nozzle. Replace the pressure gauge if it's faulty. Adjust the operating pressure as needed. Check the well water level using a water-level tester while the pump runs. Reposition the diffuser O-ring seal. Ensure the ejector is within 10 feet of the pumping level to correct oversubmergence, and adjust the ejector size and depth setting if necessary.
  • M
    Mr. John RodriguezSep 2, 2025
    Why does my Water Ace Water Pump motor overheat and shut off?
    • P
      Paula ConwaySep 2, 2025
      If the motor of your Water Ace Water Pump overheats and shuts off, the motor voltage might not match the power supply voltage. Also check for the impeller rubbing against the pump case.

Summary

Water Ace Jet Pump Installation Manual

Important Instructions Before Installation

Essential safety and operational guidelines before starting pump installation.

How to Correctly Select Your Pump

Guidance on choosing the correct pump model based on well depth and capacity.

Shallow Well Pump Installation Guide

Step-by-step instructions for installing shallow well jet pumps (RTS series).

Well Point Pump Installation

Procedures for installing pumps using a well point system.

Deep Well Pump Installation Guide

Instructions for installing deep well jet pumps without a packer.

Deep Well Packer Pump Installation Guide

Steps for installing deep well pumps with a packer system.

Pump Troubleshooting Checklist

Common pump problems, causes, and solutions.

Pump Disassembly and Repair Kits

Guidance on disassembling pumps and identifying repair kit part numbers.

Water Ace Limited Warranty Information

Water Ace RTS7 3/4 HP Specifications

General IconGeneral
Horsepower3/4 HP
Power SourceElectric
Voltage115V
Housing MaterialThermoplastic
Impeller MaterialThermoplastic
Shaft SealMechanical
Thermal ProtectionYes
Inlet Size1-1/4 in
