Assembly and Parts, Cont.
Bypass Assembly
Figure 16: Bypass Assembly
Part # Description Quantity
1 54512 Bypass Assembly (also includes items 2-6) 1
2 93860 Turbine Sensor/Cap Assembly 1
3 90809 Sensor Cap Screw, self-tapping 1
4 54320 Plastic Turbine Axle 1
5 90522 Turbine Assembly 1
6 93838 O-Ring 2
WaterBoss Softener Owner’s Manual 12/2/2010 24
