Assembly and Parts, Cont.
Top Fill Plug Assembly (950)
Figure 17: Fill Plug Assembly
Part # Description Quantity
1 93281 Fill Plug 1
2 93272 Fill Plug O-Ring 1
93281 Fill Plug
The Fill Plug (93281) seals the media access ports in the Media Tank. Care should be taken that
the O-Ring seal area is kept clean and free of debris. Also, the O-Ring should be in the proper
location in the groove. Do not overtighten the Fill Plug when assembling. When the flange comes
into contact with the Media Tank, stop tightening. A 3/4-inch socket is recommended for
assembly.
WaterBoss Softener Owner’s Manual 12/2/2010 25
