WaterLogic WL3 IT - Shipping Specifications; Electrical Specifications

WL3 IT Manual Page 10 - Revision: 6-8-2021
SHIPPING SPECIFICATIONS
ITEM Counter Top Tower
Width/Depth/Height
38.5cm x 45.2cm x 44.5cm
15.2” x 17.8” x 17.5”
38.5cm x 36.5cm x 114cm
15.2” x 14.4 x 44.9”
Weight (dry) 24 kg (52.9 pounds) 27 kg (59.5 pounds)
#Counter Top is 17.75 in. tall and may not fit between countertops and cabinets - Check installation to ensure adequate clearance.
ELECTRICAL SPECIFICATIONS
ELECTRICAL SUPPLY 120V/60Hz, 1PH 15 Amp Service
COMPONENT
POWER (approximate)
AMP DRAW (approximate)
Heater 504 4.2 Amps
Compressor
216
1.8 Amps
UV Lamp System 18 0.15 Amps
WL3 IT TOTAL
738
6.15 Amps
15.2”
17.5”
17.8”
15.2”
44.9”
14.4”
