14.2 First-time start-up defaults
The pump is preset with operational parameters as shown in table below.
Parameter 530 default
Language Not set
Default mode Manual
Default manual speed 220rpm
Pump status Stopped
Max speed 220rpm
Direction CW
Pumphead 520R2
Tube size 9.6mm
Tube material Bioprene
Flow calibration 15.12 ml/rev
Flow units rpm
SG value 1
Keypad lock Disabled
Auto-restart OFF
Analog signal type mA
Analog scaling type mA
Analog min current 5mA
Analog max current 19mA
Analog min flow rate/rpm 0rpm
Analog max flow rate/rpm 220rpm
Beeper ON
Security code Not set
MemoDose flow rate Mid flow rate of chosen pumphead
MemoDose volume 100ml
Pump number baud rate 9600
Stop bits 2
Profibus node address 126
Remote start/stop input High = stop
Leak detector input High = leak
Input 4 Disabled
Input 5 Disabled
Output 1 Run/stop
Output 1 - status High = run
