Watson-Marlow 701RA - English; Table of Contents

Watson-Marlow 701 ATEX Pumphead User Manual
PB0348:m-701atex-en-04 1
1 Declaration of conformity 3
2 Introduction 4
3 Pumphead types 5
3.1 701RA Pumphead description 5
4 Warranty 6
5 Information for returning pumps 7
6 Safety notes 7
7 Potential pump hazards 9
8 Pumphead assembly and installation 10
8.1 Installation 10
8.2 Assembly 12
8.3 Pump installation 15
9 Pumphead specification 16
10 Operating parameters 17
11 Tube life 18
12 Special conditions of use for safe operation - Tube materials suitable for use with
this equipment 19
12.1 Permissible continuous tube sizesfor IIB rating 20
12.2 Permissible LoadSure Elements for IIB rating 21
13 General operation 22
14 701REA/REXA LoadSure tube element loading 23
15 701RA/RXA Continuous Tube Loading 25
16 Maintenance 27
16.1 Track replacement 27
17 Materials of construction 29
18 Summary of modifications 30
19 ATEX marking 30
19.1 Key 30
