3 Pumphead types
The following 700 series pumpheads are covered by thismanual:
701 ATEX Pumpheads
701RA 073.0101.A00
Four Roller ATEXPumphead for 4.8mm wall continuous
tubing
701REA 073.0104.A00
Four Roller ATEXPumphead for Loadsure tubing
Elementsonly
701RXA 073.0111.A00
Four Roller ATEXExtension Pumphead for 4.8mm wall
continuous tubing
701REXA 073.0114.A00
Four Roller ATEXExtension Pumphead for Loadsure
tubing Elements only
701RGA 073.0121.A0G
Four Roller ATEXPumphead for 4.8mm GORE® STA-
PURE® Pump Tubing
* NB: these pumpheads are compatible with a number of Watson-Marlow cased drives. However, the
Watson-Marlow cased drives are not ATEXcompliant and must not be used in hazardouslocations.
Any 700 series pumpheads not listed here are NOT suitable for use in hazardous
environments (at date of issue).
3.1 701RA Pumphead description
The 701 ATEX pumpheads use the peristaltic principle by employing 4 occluding rollers assembled as a
rotor, which occludes a specially designed tube and provides fluid flow by positive displacement as it
rotates.
The pumphead is largely of coated metal construction with metal shafts for the occluding rollers. The
occluding rollers are driven by a gear within the pumphead and are of nylon construction. The rotation
of the occluding rollers is allowed using roller bearings. Materials of construction are detailed in this
manual.
The pumphead is designed to be direct mounted or close coupled onto a suitable motor gearbox using
the instructionsdetailed in this manual.
PB0348:m-701atex-en-04 5
