What elements does your package contain?
Your package contains all of the elements shown below. If any item is missing, please contact
your installer immediately.
What are the dierent parts of the Energy Monitor for?
The wireless energy monitor consists of a display unit (wireless receiver), a wireless transmit-
ter and a sensor.
Receiver
Cost - Display Electricity Cost ($)
kW/kWh - Display Energy consump-
tion ( kWh )
History - Historical data
Clear Mem – Historical data clearance
Menu Set - Menu set up
Tari - Tari set up
Max - Maximum value
Min - Minimum value
Select
- Down button
- Up button
A
B
C
D
E
F
G
Display
eA B C D F G
Transmitter
Sensor Display
LED Indicator
Sensor Plug
Wall-Mount Recessed Hole
Reset Button
Channel Switch (Channel 1-5)
Battery Housing (2 x AA batteries)
H
I
J
K
L
M
N
MKL
N
HI
J
Sensor Head
Mini jack plug
O
P
PO
Sensor
Screwdriver
4 x AA Batteries
AA AA AA AA
4 x Double-side
adhesive sticker
10 x Strip Tape
2 x Mounting plate
LED Sensor with
mini jack
(500mm cable)
Display
Unit
Power
Transmitter
To Next Page
