How do I replace batteries?
1) Power Transmitter
When the batteries in the transmitter are low on power,
an indicator on the display will be shown (Fig.1).
Remove the battery cover of the power transmitter by loosing the screws with a screwdriver
(Fig.2).
Place the 2 x AA batteries in the battery housing. The Power Transmitter will now begin to
transmit a signal. Finally the battery cover is again screwed on carefully but rmly.
NOTE: Make sure the + and – of the batteries are placed as indicated inside the
battery housing.
NOTE
IMPORTANT: For Initial set up, it is important to place batteries in the transmitter
before batteries are placed in the receiver.
Fig.2
An ID code will be shown on the display of the transmitter (Fig.2) after replacing new bat-
teries.
IMPORTANT: Do not change the preset channel of the channel switch when re-
placing batteries (Fig.3).
Fig.3
How do I replace batteries?
A
A
A
A
Fig.1
2) Display Unit
When the batteries in the Display Unit are low on power, an indicator will be shown on the
display (Fig.4).
Fig.4
Remove the battery cover at the back of the Display Unit, after 2 x AA 1.5V batteries are placed
in the battery housing, put the battery cover on again (Fig.5). Full segments on the display will
light up for a short moment.
Fig.5
SIZE AA / UM3
SIZE AA / UM3
AA
AA
