Benchmark Platinum-Edge: Operation-Service Manual
SECTION 9 AERTRIM OPERATION
OMM-0137_D • GF-211 7/16/2019 Technical Support (800) 526-0288 Mon-Fri, 8 am - 5 pm EST Page 125 of 146
BMK 1500 AERtrim Values
MENU ITEM
Minimum Maximum Default
Settle Time
0
120 Sec
20 Sec
Trim Gain 0.1 5.0 0.250
Max Tries 0 100 15
O
2
Target
(must be
between O
2
Upper & O
2
Lower)
16% 3% 8% 5.5%
30% 3% 8% 6.5%
40% 3% 8% 6.5%
50% 3% 8% 6.5%
70% 3% 8% 6.0%
100% 3% 8% 5.0%
O
2
Lower
Limit
(must be at
least 1%
lower than
O
2
Upper)
16% 2.5% 5.5% 5.0%
30% 2.5% 5.5% 5.0%
40% 2.5% 5.5% 5.0%
50% 2.5% 5.5% 5.0%
70% 2.5% 5.5% 5.0%
100%
2.5%
5.5%
4.5%
O
2
Upper
Limit
(must be at
least 1%
higher than
O
2
Lower)
16% 5.5% 8.5% 6.0%
30% 5.5% 8.5% 7.0%
40% 5.5% 8.5% 7.0%
50% 5.5% 8.5% 7.0%
70% 5.5% 8.5% 6.5%
100% 5.5% 8.5% 5.5%
O
2
Offset -3.0 3.0 1.0
BMK 1500 AERtrim Adjustment Range
CALIBRATION POINT
BLOWER VOLTAGE
Minimum Maximum Default
16% 1.40 3.30 1.80
30% 1.90 4.60 2.30
40%
2.30
5.70
2.50
50% 2.50 5.70 2.90
70% 2.70 6.30 3.80
100% 6.00 10.00 7.90
