SECTION 5 – SAFETY DEVICE TESTING
OMM-0137_D • GF-211 • 7/16/2019 Technical Support • (800) 526-0288 • Mon-Fri, 8 am - 5 pm EST Page 66 of 146
5.8 AIR FLOW FAULT TESTS - BLOWER PROOF & BLOCKED
INLET SWITCHES
These tests check the operation of the Blower Proof switch and Blocked Inlet switch shown in
Figure 5-6a, 5-6b and 5-6c.
5.8.1 Blower Proof Switch Test
Figure 5-6a: Blower Proof & Blocked Inlet Switch Locations – BMK 1500 – 3000
Figure 5-6b: Blower Proof & Blocked Inlet Switch Locations – BMK 750 &1000
BLOWER
PROOF
SWITCH
BLOCKED
INLET
SWITCH
SSOV
MANUAL
SHUT-OFF
VALVE
BLOWER PROOF
SWITCH
BLOCKED
INLET SWITCH
MANUAL
SHUT-OFF
VALVE
