Watts Aerco Benchmark Series User Manual

Benchmark Platinum-Edge: Operation-Service Manual
FORWARD
OMM-0137_D • GF-211 • 7/16/2019 Technical Support • (800) 526-0288 • Mon-Fri, 8 am - 5 pm EST Page 7 of 146
AERCO Technical Terminology Meanings
TERMINOLOGY MEANING
EMS
Energy Management System; often used interchangeably with BAS
FM Factory Mutual. Used to define boiler gas trains.
GF-xxxx Gas Fired (an AERCO document numbering system)
GND Ground
HDR Header
Hex Hexadecimal Number (0 – 9, A – F)
HP Horse Power
HX Heat Exchanger
Hz Hertz (Cycles Per Second)
I.D. Inside Diameter
IGN Ignition
IGST Board Ignition/Stepper Board, contained in Edge Controller
INTLK (INTL’K) Interlock
I/O Input/Output
I/O Box Input/Output (I/O) Box currently used on Benchmark boilers
IP Internet Protocol
ISO International Organization for Standardization
Lbs. Pounds (1 lb = 0.45 kg)
LED Light Emitting Diode
LN
Low Nitrogen Oxide
MA (mA)
Milliampere (1 thousand
th
of an ampere)
MAX (Max)
Maximum
MBH
1000 BTUs per Hour
MIN (Min) Minimum
Modbus®
A serial, half-
duplex data transmission protocol developed by AEG
Modicon
NC (N.C.) Normally Closed
NO (N.O.)
Normally Open
NOx
Nitrogen Oxide
NPT
National Pipe Thread
O
2
Oxygen
O.D. Outside Diameter
OMM, O&M Operation and Maintenance Manual
onAER
AERCO’s on-line remote monitoring system
PCB Printed Circuit Board
PMC Board Primary Micro-Controller (PMC) board, contained in the Edge
P/N Part Number
