SECTION 7 – BOILER SEQUENCING TECHNOLOGY
OMM-0137_D • GF-211 • 7/16/2019 Technical Support • (800) 526-0288 • Mon-Fri, 8 am - 5 pm EST Page 92 of 146
OPTION 5 Instructions: Remote Setpoint, Direct Wired Header Sensor, 4-20ma Setpoint Drive
Step 3: OPTION 5 CONFIGURATION
On All Boiler:
1. Go to: Main Menu  Advanced Setup  BST Cascade  Cascade Configuration:
• Set the Unit Mode parameter to BST Client.
2. Go to: Main Menu
 Advanced Setup  BST Cascade  Application Configuration:
• Set the Unit Address parameter to the communication address of the unit.
On the Manager only:
1. Go to Main Menu  Advanced Setup  BST Cascade, set the Parameters to the Values
in each menu in the table below.
Menu/Screen Name
Parameters
Values
Cascade
Configuration
Unit Mode
BST Manager
Hdr Temp Sensor
Header Temp
Application
Configuration
Application
Space Heating
SH Operating Mode
Rmt Setpt Analog
BST Remote Signal
4-20mA/1-5V *
Cascade Comm
Min address
The minimum unit address in the cascade
Max address
The maximum unit address in the cascade
Cascade Baud Rate
The baud rate for the cascade.
* Be sure that the SW1-4 DIP switch on Controller’s Interface Board is set appropriately (On = Current,
Off = Voltage.)
