Due to technical progress, all designs, specifications and components are subject to change without notice.
FACTSHEET F-200
FLE–140–01–G–DV
FLE–110–01–G–DV
FLE–120–01–G–DV
Tiger Beam
contact
Surface
Mount
(1,27mm) .050"
micro pitch
Available with optional
pick-and-place pads
Ideal for
pass-through
applications
Processing:
Max Processing Temp:
230°C for 60 seconds
SMT Lead Coplanarity:
(0,10mm) .004" max
Suggested Paste
Thickness:
For most applications add
(0,05mm) .002" to max SMT
lead coplanarity
Suggested PCB Layouts:
Your specific layout may
vary
STANDARD SOCKET
FLE SERIES
TAPE & REEL AVAILABILITY
Call Samtec for specifications
and ordering information.
No tooling charges.
125 piece minimum order.
Order any quantity above minimum.
In-house design, manufacture.
Quick turn-around.
01
PLATING
OPTION
NO. PINS
PER ROW
1
FLE
–G
= 10µ" (0,25µm) Gold
DV
OPTIONS
–A
= Alignment Pin
(Metal or plastic at
Samtec discretion)
–K
= (Best Cost Option)
(4,00mm) .157" DIA
Polyamide film
Pick & Place Pad
(5 Positions minimum)
–P
= Metal Pick &
Place Pad
(5 Positions minimum)
–TR
= Tape & Reel
Packaging
Mates with:
FTSH, FTS, FW
05 thru 50
–P OPTION
Board fixturing may be required
to assure proper alignment for
pass-through applications.
Note: Some lengths, styles
and options are non-standard,
non-returnable.
(5,21)
.205
(0,74)
.029
DIA
(Pass-Thru)
(0,74)
.029
(1,47)
.058
(1,27)
.050
(1,27)
.050
TYP
(0,74
-0,00
+0,08
)
.029
-.000
+.003
DIA (2)
SPECIFICATIONS
Materials:
Insulator Material:
Black Liquid Crystal Polymer
Contact Material:
Phosphor Bronze
Current Rating:
1.75A @ 80°C ambient
Operating Temp Range:
-65°C to +125°C
Plating:
Au over 10µ" (0,25µm) Ni
Contact Resistance:
15mΩ max
Insertion Depth:
(1,83mm) .072" to
(4,37mm) .172" with
(0,38mm) .015" or
pass-through
Insertion Force:
1.5oz (0,42N)
Normal Force:
100 grams (0,98N)
Withdrawl Force:
1.5oz (0,42N)
Max Cycles:
100+
Surface
SMT
Mount
C
O
S
T
S
A
V
I
N
G
S
O
L
U
T
I
O
N
S
Flex
Cable
FTSH
Serie
s
FLE
Series
APPLICATION
No. of Positions x (1,27) .050 + (0,11) .0045
(1,27)
.050
(1,27)
.050
(0,51)
.020
(3,33)
.131
(4,55)
.179
(4,36)
.172
(4,74)
.187
(6,35)
.250
x
(4,17)
.164
(4,60)
.181
