DiGiGrid D / User Guide
16
HEADPHONES
Gain Range Infinity: To +10 dB
Max Output Level:
Load RMS
16Ω 2.3V
32Ω 3.7V
100Ω 6.0V
200Ω 7.5V
600Ω 8.8V
XLR CONNECTORS
Phase Termination Point
Positive (+) Pin 2
Negative (-) Pin 3
Signal Ground Pin 1
Chassis Ground Case
¼” TRS CONNECTORS
Phase Termination Point
Positive (+) Tip
Negative (-) Ring
Signal Ground Sleeve
DIMENSIONS
Width: 22.05 cm / 8.68 inches
Height: 7.85 cm / 3.09 inches
Depth: 16 cm / 6.29 inches
Device Weight: 1.7 kg / 3.75 lbs
Package Weight: 2.72 kg / 6 lbs
