DiGiGrid D / User Guide
5
Getting Started
Configure SoundGrid and assign your devices as follows, however large or small your system.
Connect the hardware
Install the software
Configure your system
Connect the Hardware
One I/O
In this example, one DiGiGrid D is used to connect a console to the SoundGrid host application’s SoundGrid ASIO/Core
Audio driver for plugin processing and/or DAW playback/recording. The interface is connected directly to the host using a
Cat 5e Ethernet cable or better.
SoundGrid host computer
SoundGrid I/O device
The LAN port that’s connected to the SoundGrid network should be used for SoundGrid only. Do not share this port with
the internet or other networks.
In this configuration, all plugin processing is carried out on the host computer. The speed and power of the host defines
overall latnecy.
