4.2inch e-Paper Module User Manual

V2.0 17 / 25

ARDUINO

Note: If the driver board you bought is e-Paper shield, you can use the demo codes

provided for e-Paper shield separately which can be downloaded in corresponding

wiki.

HARDWARE CONNECTION

If you use other Arduino board instead of Arduino UNO, you should check if its

interfaces are compatible with UNO.

e-Paper

Arduino UNO

3.3V/5V

3V3/5V

GND

DIN

D11

CLK

D13

D10

RST

BUSY

RUNNING EXAMPLES

1. Make sure you have installed Arduino IDE in your PC

2. Open Arduino project

3. Select correct Board and Port

4. Compile and upload to Arduino board
