4.2inch e-Paper Module User Manual

V2.0 8 / 25

⚫ Consumption

◼ Refresh consumption: 26.4mW(typ.)

◼ Standby consumption: <0.017mW

⚫ Viewing angle: >170°

INTERFACES

VCC

：3.3V/5V

GND

：GND

DIN

：SPI MOSI pin

CLK

：SPI SCK pin

：SPI chip selection, low active

：Data/Command Selection（High: Data; Low: Command）

RST

：Reset（Low active）

BUSY

：Busy（Low active）

These are experimental data; actual data may be different according to working situation
