NRF52840 Eval Kit User Manual
Vision: V1.0.1 Date: 2019.01.19 63 / 72
⚫ Server:
◼ During provisioning process:
◆ LED3 and 4 blinking: Device identification active
◆ LED1 to 4: Blink four times to indicate provisioning process is
completed
◼ After provisioning and configuration is over:
◆ LED1: Reflects the value of OnOff state on the server
⚫ LED ON: Value of the OnOff state is 1 (true)
⚫ LED OFF: Value of the OnOff state is 0 (false).
⚫ Client:
◼ During provisioning process:
◆ LED3 and 4 blinking: Device identification active
◆ LED1 to 4: Blink four times to indicate provisioning process is
completed
◼ After provisioning and configuration is over, buttons on the client are
used to send OnOff Set message to the servers:
◆ Button1: Send a message to the odd group(address: 0xC003) to turn
on LED1
◆ Button2: Send a message to the odd group (address: 0xC003) to turn
off LED1
◆ Button3: Send a message to the even group (address: 0xC002) to
turn on LED1
