Noise
Clock
Frequency
Switch
selectable noise
frequencies are
listed
below.
Clock
Frequency
160
Hz
1.6
kHz
16
kHz
160
kHz
1.6
MHz
Analog
Noise
Bandwidth
10
Hz
100
Hz
1
kHz
10
kHz
100
kHz
ENVIRONMENTAL
Temperature
All
specifications
listed, except stability,
are for
25
C
±5°C.
For
operation from
0°C
to 55°C,
derate all
specifications
by
factor
of
2.
MECHANICAL
OPERATIONAL
MODES
FUNC
Function
Mode
—
Provides the
selected
wave-
form at the
main output.
S/N
Signal-to-Noise
operation adds
noise to
a
selected
signal of
constant
amplitude. The
signal-to-noise ratio
is
variable
from
0
to
+60 dB.
N/S
Noise-to-Signal
operation adds
a
selected
signal
to a
constant
amplitude
noise. The
noise-to-signal ratio
is
variable
from
0
to
+60 dB.
FM
Frequency
Modulation
—
Provides random modu-
lation
of the
frequency
of the generator.
The
S/N
-
N/S
(dB)
ratio control
also controls
the amount of
fre-
quency
deviation.
NOTE
Dimensions
8V
2 inches
wide,
5% inches
high,
1
1
V
2
inches
deep
Weight
8
lbs net,
12 lbs shipping
Power
105
V to 125
V or 200
V
to 250
V,
50
Hz
to 400
Hz.
Less
than 1
5
watts.
NOTE
All
specifications apply
for frequencies
obtained
when dial is
between 0. 1 and
2.0
and at
10 V
p-p
into
a
50
ohm
load.
When
noise
is
added
to the
signal output,
specifications apply up to 200
kHz
and
the
square wave
rise
time is
derated by
a
factor of
10. In
the
dock
range of
1.6
MHz,
the
maximum
calibrated signal-
to-noise
ratio
is
30
dB.
It is
possible to stop
the generator from
oscillating
by
applying a
negative VCG
voltage
when the dial is
already
set at
minimum frequency.
VCG inputs
up
to
30
V will not permanently damage the
instrument.
