5-2 Model 9100 — Operator's Guide: DC Current Function
User's H'b'k
Page Ref
Fig. 5.2
Connections for DCI 'AUX OUTPUT' UUT Calibration
10A mA COM V-
A
A
A
A
A
A
A
Cap
+
-
Thermo
Couple
+
-
I+mAI+ 20ALI-
sLsHH
WhiYellBlkBlkRedRed
Adaptor Parking Holes
Work Mat
UUT
5
DC Current Calibration (Contd.)
5.1 Interconnections (Contd.)
