Software Option 897 808
Operating Instructions
(62_tetra) Doc. Version: 0007-210-A
Wavetek Wandel Goltermann, Gutenbergstr. 2 – 4, D-85737 Ismaning
!
+49 (89) 9 96 41-0 Fax: +49 (89) 9 96 41-160
4
0
3
1
4
0
3
2
Supplement to operating manual; file under Chapter 10
TETRA MS Test
10

Table of Contents

Questions and Answers

  • J
    james33Aug 11, 2025
    What to do if Wavetek TETRA MS Test Test Equipment MEASURE mode shows no results?
    • Y
      yorkcaseyAug 11, 2025
      If the Wavetek Test Equipment in MEASURE mode displays no results, there could be a couple of reasons. First, ensure a signal is present at the connector indicated in the DEF.SET menu (RF or RF-DIR). Second, the signal source might be on a different frequency than expected. Verify the mobile station's actual TX frequency using the Spectrum ANALYZER and adjust the channel number and Channel 0 TX Frequency accordingly.
  • M
    Matthew PattonAug 20, 2025
    Why Wavetek Test Equipment CALL mode MS does not register?
    • A
      Aimee SanchezAug 20, 2025
      If the MS does not register with the STABILOCK 4032 in CALL mode, consider the following: 1. The frequency might be incorrect; determine the channels used by the system for which the MS is programmed and enter the channel 0 frequency in the DEF.SET mask. 2. The setup might be for the wrong connector; check if the signal is applied to the same connector as indicated in the DEF.SET menu (RF or RF-DIR; the RF-DIR socket provides 20 dB higher input/output level). 3. The MCC (mobile country code) and/or MNC (mobile network code) might be wrong; select MCC according to the country in which the MS is used. A list of MCC’s is provided in the appendix of this manual.
  • N
    Nicole ColeAug 31, 2025
    How to troubleshoot Wavetek TETRA MS Test Test Equipment MEASURE mode when result fields indicate "-----" only?
    • D
      dmercerAug 31, 2025
      If the result fields in MEASURE mode of your Wavetek Test Equipment display "-----", it could be due to these reasons: * The signal might be unmodulated or using a modulation format other than TETRA. * The RF power might be too low. Ensure you're applying at least –15 dBm or 0.03 mW to the RF connector. You can verify the mobile station’s power level using the Spectrum ANALYZER.

Wavetek TETRA MS Test Specifications

General IconGeneral
Power Supply100-240 VAC, 50/60 Hz
InterfaceRS-232, GPIB
Signaling TestSupported
Audio Quality MeasurementsSupported
Bit Error Rate (BER) TestingSupported
Modulationπ/4-DQPSK
