Pinning of RS-232-C interface
Bu 105
Pin 1 = DCD Pin 5 = GND
Pin 2 = RXD Pin 6 = nc
Pin 3 = TXD Pin 7 = RTS
Pin 4 = DTR Pin 8 = CTS
Pin 9 = nc
TETRA MS Test RS-232-C interface
10-44
