What is tested EVERYWHERE?
The TETRA MS Test option allows you to
•
perform transmitter tests on TETRA mobile stations as well as base stations.
•
stimulate the TETRA mobile receiver with a T1 (standard TETRA test) signal.
•
view the signalling protocol exchanged between the TETRA mobile station
and the STABILOCK 4032.
•
loop back the audio signal from the microphone to the loudspeaker for a quick
go-nogo test.
•
trace back the measurement results to the right unit under test, and to test the
numerical keypad.
Measurements possible with TETRA – an overview
Registration RF power
Call from mobile station Frequency error
Call from base station Residual carrier power
Peak and RMS vector error Phase error
Timing error (alignment) Power over time (graphics)
Constellation display (graphics) Modulation spectrum (graphics)
Paging sensitivity –
TETRA MS Test Introduction
10-6
