Model 9100 — About the Operator's Guide 1-1
User's H'b'k
Page Ref
About the Operator's Guide
1
Section 3
of the
User's Handbook
for the Model 9100
should be used to gain practice at manipulating
front-panel controls.
For an introduction to 'Procedure Mode', refer to
Section 5
of the
User's Handbook
. For the use of
other modes refer to
Section 3
of the
User's
Handbook
.
Section 4
of the
User's Handbook
shows, in a
general way, the 'Manual Mode' facilities of the 9100
for calibration of a manually-operated measuring
instrument. It is divided into sub-sections each
dealing with 'Functions' (DC Voltage, AC Voltage
etc.). Each sub-section carries a specimen procedure
for calibrating that function in a 'general' UUT. This
'Operator's Guide' repeats these procedures in a
more convenient form.
This Guide is divided into the following Sections:
4.2-1
4.3-1
4.4-1
4.5-1
4.6-1
4.7-1
4.8-1
4.9-1
4.10-1
4.11-1
4.12-1
4.13-1
4.14-1
4.15-1
4.16-1
4.17-1
8 App A
2 Interconnections
3 DC Voltage
4 AC Voltage
5 DC Current
6 AC Current
7 Resistance
8 Conductance
9 Frequency
10 Mark/Period
11 % Duty
12 Auxiliary Functions
13 Capacitance
14 Temperature — Thermocouple
15 Temperature — RTD
16 Logic Pulses
17 Logic Levels
18 Error Messages
