Connecting to LAN
If you want to be able to control the system via the Sentio
App, the CCU must be connected to your router. This is
done with a standard netcable (RJ45 plug), which is con-
nected to port M at the bottom of the CCU.
Connecting the Commissioning Touch Screen
To get a complete overview of the whole installation and
be able to set up all parameters for the system a commis-
sioning touch screen can be connected. It is connected
with a standard netcable (RJ-45 plug) into port J or L at
the CCU/EU.
Connecting a Smart Radiator Thermostat
After attaching the M28, M30 or RA adapter on the ther-
mostatic valve the Radiator Thermostat(XVI) can be clicked
on. To enroll this component, select a room channel on the
CCU and insert the batteries or use the commissioning tool.
If the Radiator Thermostat (XVI) is in a position where it is
not properly able to measure the room temperature, add
a room Thermostat(I)/Sensor(II) to improve temperature
measurements.
Connecting a Dehumidifier unit
For humidity control and optimized cooling a dehumidifier
can be added to the system via an Extension Unit with
relays (VI). By connecting the dehumidifier connection (“D”)
and the thermal integration connection (“TI”) according to
the pre-set sub-profiles as shown in the table below to
enroll all units at once. Wavin can offer dehumidifier units
P300, S300, and dehumidifier units with heating/cooling
coil PC300 and SC300 for this functionality. For more
information on dehumidifier see the Technical Handbook at
www.wavin.com/Sentio.
Limitations
The Sentio system can contain a fixed maximum number of
components. Keep these in mind when designing a system.
Max
Rooms 24
Thermo Actuators 24V DC 1W 16
Dehumidifiers 4
Room Thermostats/Sensors 24
Outdoor Temperature Sensor 1
Smart Radiator Thermostat 16
Extension Unit (EU-A) 2
Extension Unit with VFR (EU-VFR) 2
Touch Screen Commissioning tool 2
5
Pre-set Unit Connections to Extension Unit (EU-VFR)
A B C D E F
1.1 1 x Dehumidifier (P/S300) D
1.2 2 x Dehumidifier (P/S300) D D
1.3 3 x Dehumidifier (P/S300) D D D
1.4 4 x Dehumidifier (P/S300) D D D D
2.1 1 x Dehumidifier with H/C coil (PC/SC300) D TI
2.2 2 x Dehumidifier with H/C coil (PC/SC300) D TI D TI
2.3 3 x Dehumidifier with H/C coil (PC/SC300) D TI D TI D TI
