placed at the top of the section(s).
NOTE: If your door was ordered with the All Windows option, two struts are temporarily fac-
tory attached to the section. Both struts are to be permanently fastened during installation.
NOTE: If you paint your door, follow the Strutting Schedule For Brown, Black and Woodgrain
Colored Doors.
Strutting Schedule Key:
TS = Top Section I1 = Intermediate Section #1
IW = Intermediate Section With Windows LS = Lock Section
I6 = Intermediate Section #6 BS = Bottom Section
I5 = Intermediate Section #5 ES = Every Section gets a strut.
I4 = Intermediate Section #4 RS = Remaining Sections gets a strut.
I3 = Intermediate Section #3 2S = 2” Strut
I2 = Intermediate Section #2 3S = 3” Strut
Strutting Schedule For Model 8300 Steel (White, Almond, and Taupe Colored Doors)
Door
Heights
Section
Quantity
Door
Configu-
rations
Door Widths
10’0” -
14’0”
15’0” -
16’0”
17’0” -
18’0”
20’0”
< = 8’0” 4 Solid / Top
(Windows)
2S, TS 2S, TS /
2S, LS
2S, TS /
2S, LS /
2S, BS
3S, ES
5 Solid / Top
(Windows)
2S, TS /
2S, I1
2S, TS / 2S,
I1 / 2S, BS
4 or 5 Inter-
mediate
(Windows)
2S, TS /
2S, IW
2S, TS / 2S, IW / 2S, BS
> 8’0” 5 Solid 2S, TS 2S, TS / 2S,
I1 / 2S, BS
2S, ES N/A
Top (Win-
dows)
3S, TS /
2S, RS
Inter-
mediate
(Windows)
2S, TS /
2S, IW
2S, TS /
2S, IW /
2S, BS
2S, ES
6 Solid 2S, TS 2S, TS / 2S,
I2 / 2S, BS
2S, ES N/A
Top (Win-
dows)
3S, TS /
2S, RS
Inter-
mediate
(Windows)
2S, TS /
2S, IW
2S, TS /
2S, IW /
2S, BS
2S, ES
12’0” -
14’0”
7-9 Solid 2S, TS 3S, TS / 2S,
I3 / 2S, I1 /
2S, BS
3S, TS / 2S,
I4 / 2S, I3 /
2S, I2 / 2S,
I1 / 2S, BS
N/A
Top (Win-
dows)
Inter-
mediate
(Windows)
2S, TS /
2S, IW
3S, TS / 2S,
IW / 2S, I1
/ 2S, BS
Strutting Schedule For Models 8300 / 8300 Sonoma Wood Grain Steel (Brown, Black and
Woodgrain Colored Doors)
Door
Heights
Section
Quantity
Door
Configu-
rations
Door Widths
10’0” 12’0” -
16’0”
17’0” -
18’0”
20’0”
< = 8’0” 4 Solid / Top
(Windows)
2S, TS 2S, TS /
2S, LS /
2S, BS
3S, TS /
3S, LS /
3S, BS
3S, ES
Inter-
mediate
(Windows)
2S, TS /
2S, IW
2S, TS /
2S, IW /
2S, BS
3S, TS /
3S, IW /
3S, BS
5 Solid / Top
(Windows)
2S, TS 3S, TS / 3S, I1 / 3S, BS 3S, ES
Inter-
mediate
(Windows)
2S, TS /
2S, IW
3S, TS / 3S, IW / 3S, BS
Strutting Schedule For Models 8300 / 8300 Sonoma Wood Grain Steel (Brown, Black and
Woodgrain Colored Doors)
Door
Heights
Section
Quantity
Door
Configu-
rations
Door Widths
10’0” 12’0” -
16’0”
17’0” -
18’0”
20’0”
> 8’0” 5 Solid / Top
(Windows)
2S, TS 3S, TS / 3S,
I1 / 3S, BS
3S, ES N/A
Inter-
mediate
(Windows)
2S, TS /
2S, IW
3S, TS /
3S, IW /
3S, BS
6 Solid / Top
(Windows)
2S, TS 3S, TS / 3S,
I2 / 3S, BS
3S, ES N/A
Inter-
mediate
(Windows)
2S, TS /
2S, IW
3S, TS /
3S, IW /
3S, BS
12’0” -
14’0”
7 - 9 Solid / Top
(Windows)
2S, TS /
2S, I1
3S, TS / 2S,
I3 / 2S, I1
/ 2S, LS /
2S, BS
3S, ES N/A
Inter-
mediate
(Windows)
2S, TS /
2S, IW
3S, TS / 2S,
IW / 2S, I1
/ 2S, LS /
2S, BS
Strutting Schedule For Model 8500 Steel (White, Almond & Taupe Colored Doors)
Door
Heights
Section
Quantity
Door
Configu-
rations
Door Width
10’0” 12’0” -
14’0”
15’0” -
16’0”
17’0” -
18’0”
20’0”
< = 8’0” 4 Solid N/A 2S, TS 2S, TS 2S, TS /
2S, LS /
2S, BS
3S, ES
Top (Win-
dows)
2S, TS 3S, TS /
2S, LS /
2S, BS
Inter-
mediate
(Win-
dows)
N/A 2S, TS /
2S, IW
2S, TS / 2S, IW /
2S, BS
5 Solid N/A 2S, TS 2S, TS 2S, TS /
2S, I1 /
2S, BS
3S, ES
Top (Win-
dows)
2S, TS 3S, TS /
2S, IW /
2S, BS
Inter-
mediate
(Win-
dows)
N/A 2S, TS /
2S, IW
2S, TS / 2S, IW /
2S, BS
> 8’0” 5 Solid N/A 2S, TS 2S, TS /
2S, I1
2S, TS /
2S, I2 /
2S, I1 /
2S, BS
N/A
Top (Win-
dows)
2S, TS 3S, TS /
2S, I2 /
2S, I1 /
2S, BS
Inter-
mediate
(Win-
dows)
N/A 2S, TS /
2S, IW
2S, TS /
2S, IW /
2S, BS
2S, TS /
2S, IW /
2S, I1 /
2S, BS
6 Solid N/A 2S, TS 2S, TS /
2S, I2
2S, TS /
2S, I2 /
2S, I1 /
2S, BS
N/A
Top (Win-
dows)
2S, TS 3S, TS /
2S, I2 /
2S, I1 /
2S, BS
Inter-
mediate
(Win-
dows)
N/A 2S, TS /
2S, IW
2S, TS /
2S, IW /
2S, BS
2S, TS /
2S, IW /
2S, I1 /
2S, BS
9
