APPLICATION AND OPERATION
Do NOT use pump if any part of the housing
switch, probe, or power cord is cracked, broken, or missing.
NE PAS utiliser
la pompe si une partie quelconque du
commutateur de boîtier, de la sonde de
capteur ou du cordon d'alimentation est
fi ssurée, brisée ou manquante.
Always disconnect electric supply before
attempting to install, service, relocate, or perform any maintenance. If
the power source is out of sight, lock and tag in open (off) position to
prevent unexpected power application. Failure to do so could result in
fatal electrical shock!
Toujours couper le courant avant d'essayer
d'installer, de réparer, de déplacer ou d'effectuer toute
opération de maintenance. Si la source d'alimentation est
hors de vue, verrouiller et étiqueter en position ouverte (off)
pour éviter une décharge électrique inattendue. Ne pas le
faire pourrait entraîner un choc électrique mortel.
Use polarized grounding type plugs only.
Polarized plugs have one blade slightly wider than the other and can
only be inserted one way into the outlet. Do NOT handle plug connector
near water. Failure to follow these instructions will result in serious
injury or death.
Utiliser seulement des fi ches de masse
polarisées. Les fi ches polarisées ont une lame légèrement plus large
que l'autre et ne peuvent être insérées dans la prise que d'une seule
manière. NE PAS manipuler le connecteur près de l'eau. Le non-respect
de ces instructions ENTRAÎNERAIT de graves blessures ou la mort.
This unit is NOT designed for use as a sump
pump or in sump applications, this will void warranty. This unit is NOT
designed for use in septic tanks or underground vaults to pump raw
sewage or effl uents. NEVER use in hazardous or explosive locations.
Cette unité n'est PAS conçue pour être utilisée
comme pompe de puisard ou dans des applications de
puisard, cela annulera la garantie. Cette unité n'est PAS
conçue pour être utilisée dans des fosses septiques ou
des enceintes souterraines pour pomper les eaux usées ou
les effl uents. Ne JAMAIS utiliser dans des environements
dangereux ou explosifs.
1. This pump has been designed with 1-1/4 in. NPT discharge
connection size. Attach pipe or fitting to the discharge or use
the supplied garden hose adapter. Thread the female end of the
garden hose to the male end of the elbow.
2. Be certain to use a hose washer (not included) on the garden
hose for correct pump operation.
3. For best pump performance, unwind the hose before starting
the pump. This will help remove any kinks or binds in the hose
and allow the unit to pump with less restriction.
4. Set the pump on a hard, flat surface in the water. Do not set
the pump directly on mud or sand surfaces. This will cause the
inlet to clog.
5. The water level must be at least 1-3/4 inches for the pump to
cycle, prime, and operate. Water levels less than 1-3/4 inches
will not allow the impeller to contact water therefore no water
will be pumped.
Do NOT use pump with wet hands or when
standing in water or on a damp surface when the unit is operating
or fails to operate. ALWAYS disconnect pump power cord from power
source before handling.
NE PAS utilisation pomper avec les mains
humides ou debout dans l'eau ou sur une surface humide lorsque
l'appareil fonctionne ou ne fonctionne pas correctement. TOUJOURS
débrancher le cordon d'alimentation de la pompe de la source
d'alimentation avant toute manipulation.
6. Plug the pump into a 120 volt GFCI protected outlet. The
pump will start pumping automatically when the water reaches
a depth of 1-3/4 inches. A priming delay of 2 seconds is
programmed into the control to allow time for air to escape
from the pumping chamber.
7. The pump will stop automatically once water has been
removed to a depth of approximately 3/8 of an inch above the
hard surface. The pump will not restart until the water depth
rises to 1-3/4 inches or greater.
8. The pump will not allow itself to run dry. Once the pump
detects that water is no longer being removed, it will shut down
automatically. The pump must remain upright at all times in order
for the water detection to function. Do not allow the pump to
operate on its side or inverted.
Do NOT alter the pump to override the automatic
water detector. The shaft seal depends on water for lubrication.
Overriding this pump feature can cause the pump to run dry and may
damage the shaft seal and cause pump failure and void warranty.
DESCRIPTION
This portable, submersible Multi-Use pump is designed for
automatic use in water. The units are equipped with a 9 ft. 3-prong
grounding type power cord. The provided discharge adapter can
be used for convenient attachment to a garden hose.
Installation of this pump outdoors, unprotected from the weather,
may cause hazardous conditions and will void warranty. If using
outdoors, protect pump from direct weather elements such as sun,
rain, sleet, snow, and extreme temperature changes. Water inside
the pump may freeze, limiting its performance and damaging the
pump, pipes, and hoses.
UNPACKING
Inspect this unit before it is used. Occasionally, products are
damaged during shipment. If the pump or components are
damaged, contact Customer Support at 1-800-237-0987.
2
www.waynepumps.com
QUICK START MANUAL
LIMITED WARRANTY
For one year for EEAUP250 model from the date of purchase, from an authorized dealer, Wayne Water Systems will repair or replace, at its option for the original
purchaser, any part or parts of its Multi-Use Pumps or Water Pumps (“Product”) found upon examination by Wayne Water Systems to be defective in materials or
workmanship. Please call Wayne Water Systems (800-237-0987) for warranty instructions. Be prepared to provide the model number and the serial number when
exercising this warranty. All transportation charges on Products or parts submitted for repair or replacement must be paid by purchaser.
This Limited Warranty does not cover Products which have been damaged as a result of accident, abuse, misuse, neglect, improper installation, improper maintenance,
or failure to operate in accordance with Wayne Water Systems’ written instructions.
THIS WARRANTY IS IN LIEU OF ANY AND ALL OTHER WARRANTIES, OBLIGATIONS OR AGREEMENTS, EXPRESSED OR IMPLIED, INCLUDING ANY IMPLIED WARRANTY
OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE, AND ANY RIGHTS OR REMEDIES AGAINST ANY PERSON OR ENTITY UNDER THE UNIFORM
COMMERCIAL CODE OR OTHERWISE WITH RESPECT TO THE SALE OF THE PRODUCT. THE REMEDIES AND OBLIGATIONS STATED IN THIS WARRANTY ARE THE SOLE
AND EXCLUSIVE REMEDIES OF AND OBLIGATIONS TO THE OWNER FOR ANY AND ALL MATTERS ARISING WITH RESPECT TO OR IN ANY WAY CONNECTED WITH
THE PRODUCT, REGARDLESS OF THE SOURCE OR PROVIDER OF SUCH GOODS. IN NO EVENT, WHETHER AS A RESULT OF BREACH OF CONTRACT, WARRANTY TORT
(INCLUDING NEGLIGENCE) OR OTHERWISE, SHALL WAYNE WATER SYSTEMS OR ANY AFFILIATE BE LIABLE FOR ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL
DAMAGES.
You MUST retain your purchase receipt along with this form. In the event you need to exercise a warranty claim, you MUST send a copy of the purchase receipt along
with the material or correspondence. Please call Wayne Water Systems (800-237-0987) for return authorization and instructions.
DO NOT MAIL THIS FORM TO Wayne Water Systems. Use this form only to maintain your records.
MODEL NO._____________________ SERIAL NO._________________________ INSTALLATION DATE __________________________
ATTACH YOUR RECEIPT HERE
