SECTION VI: PARTS LIST AND EXPLODED VIEWS
HSG200/400 PARTS LIST
Item
Part No.
Description
1
100934-001
Burner Housing
2
62576-SER6
Air Tube - HSG200 6" (152.4mm)
63270-004
Air Tube - HSG400 6 1/4" (158.75mm)
62576-SER9
Air Tube - HSG200 9" (228.6mm)
63270-015
Air Tube - HSG400 9" (228.6mm)
62576-SER12
Air Tube - HSG200 12" (304.8mm)
63270-027
Air Tube - HSG400 12" (304.8mm)
63270-028
Air Tube - HSG400 15" (381mm)
3
62393-SER
Air Cone - (HSG200 only) (not shown)
4
21724-011
Adjustable Flange Assembly (includes gasket, not shown)
5
100428-002
Flange Gasket (not shown)
6
21664
Blower Wheel 5 1/4" OD (133.35mm) (HSG200)
21642
Blower Wheel 5 1/2" OD (139.7mm) (HSG400)
7
21658
Side Plate
8
20627
Motor, split phase 1/7 HP (0.107 kW) 3450 RPM 120V/60
24001-001
Motor, 1/7 HP (0.107 kW) 2850 RPM 230V 50/60 Hz
9
100373-002
Combustion Air Inlet damper
10
62408-001
Control Box (S89E & S89F)
11
62388-001
30 second Pre-purge Timer (Used with P/N 62758-002) (Special Limit Applications Only)
62530-001
Resistor Wire Assembly
12
60186-004
24 Volt Transformer 120V
64404-001
24 Volt Transformer 230V 50/60 Hz
100450-001
Bushing
13
62406-002
Motor Relay
14
62759-002
Ignition Control Honeywell S89F with 30 sec. Pre-purge
62758-002
Ignition Control Honeywell S89E with 0 sec. Pre-purge (Special Limit Applications Only)
64420-002
Ignition Control, Wayne with 30 sec. Pre-purge
15
100377-002
Damper Indicator Pointer
16
100429
Damper Decal
15-16
100373-KIT
Includes 100373-002, 100429, 100377-002 and 100410
17
63263-005
Pressure Switch
63272-005
Pressure Switch Conversion Kit
63935-001
Pressure Switch (230V/50Hz)
18
60178-002
Thermostat Terminal Strip
19
100372
Adjustment Arm Off-Cycle Damper
20-21
100371-KIT
Off-cycle Damper Kit (not shown)
22
21319
Junction Box (under Ignition Transformer)
23
61843
Lighting Plate
24
62407-001
Ignition Transformer 120V/60 Hz
24
64051-001
Ignition Transformer 230V 50/60 Hz
25
62391-002
Electrode Assembly
26
62390-002
Sensor Probe (flame sensor) Assembly
27
62387-001
Insulator Bushing (QTY 2 REQUIRED ON HSG BURNER)
28
62575-002
Chamber/Manifold - HSG200 6" (152.4mm)
62575-001
Chamber/Manifold - HSG400 6 1/4" (158.75mm)
62575-014
Chamber/Manifold - HSG200 9" (228.6mm)
62575-012
Chamber/Manifold - HSG400 9" (228.6mm)
62575-026
Chamber/Manifold - HSG200 12" (304.8mm)
62575-024
Chamber/Manifold - HSG400 12" (304.8mm)
62575-031
Chamber/Manifold - HSG400 15" (381mm)
29
62419-001
Clip, Electrode Bracket
30
61951-001
Igniter Support Parts Kit (INCLUDES 62419-001 and 62387-001) (not shown)
31
62411-028
11" (279.4mm) Sensor Wire - 6" (152.4mm), 6 1/4" (158.75mm) Burner
62411-030
14" (355.6mm) Sensor Wire - 9" (228.6mm), 12" (304.8mm) Burner
62411-068
17" (431.8mm) Sensor Wire - 15" (381mm) Burner
64096-001
Sense Wire - 330mm Cable (230V 50/60 Hz)
PARTS LIST CONTINUED ON NEXT PAGE.
