5
Operating Instructions and Parts Manual
JSU50
www.waynepumps.com
Distance, in Feet, From Motor to Supply
Fuse (AWG Wire Size)
Rating 0 51 101 201
Model HP Volts Amps 50 100 200 300
JSU50 1/2 120 15 14 14 12 10
230 10 14 14 14 14
WIRING CHART - RECOMMENDED WIRE AND FUSE SIZES
Feet Friction Loss in 100 Feet of Plastic Pipe
Gallons Per Minute
Pipe Size 20 25 30 40 50 60 80 100 120
1
1
⁄
4” 5.6 8.5 11.9 20.2 30.5
1
1
⁄
2” 2.6 4.0 5.5 9.4 14.3 19.9 34.2
2“ 1.2 1.6 2.8 4.2 5.8 9.9 15.0 21.2
2
1
⁄
2“ 1.2 1.8 2.5 4.2 6.3 8.8
FRICTION LOSS CHART
