Wayne P250 Instructions

6
NOTE: The BTU input valves on the preceding page show the approximate hourly input of the burner for the various drill
sizes shown. To determine the actual input of the burner:
1)
Turn off all other gas appliances.
2) The hand on the dial with the lowest cubic feet value (fastest revolving dial) should be clocked for one complete revolution.
3) Divide 3,600 by the time in seconds for one complete revolution and multiply by the dial value (1, 2, or 5 cubic feet
depending on size of meter
.)
4) Multiply this by the heating value of the gas to obtain the input to the burner in BTU per hour.
EXAMPLE: Time in seconds for one complete revolution of dial is 72. 3,600 divided by 72 is 50, a 2 cubic foot dial was timed
therefore 50 x 2 is 100. Multiply 100 by heating value of gas which is 1,000 and this will give you an input of
100,000 BTU per hour.
IMPORTANT: The minimum gas supply pressure is 4.5” w.c. (1121Pa) for natural gas and 11.0” w.c. (2740Pa) for L.P. gas;
the maximum gas supply pressure is 10.5” w.c. (2615Pa) for natural gas and 13” w.c. (3238Pa) for L.P. gas.
P250 ONLY
Input Floor Area Preferred Recommended Recommended
BTU/Hr
. Sq. Inches Width and Minimum Minimum
(kW/Hr
.) (mm
2
)
Length (mm) Wall Thickness Floor Construction
50,000 (14.65)
49 (31610) 7(177.8)x7 (177.8) 2 1/2” (63.5mm) 2 1/2” (63.5mm)
85,000 (24.91 56 1/4 (36290) 7 1/2(190.5)x7 1/2(190.5) insulating firebrick Insulating firebrick
100,000(29.31)
64 (41290) 8(203.2) X 8(203.2) plus back up of plus 1 1/2” (38.1mm)
120,000(35.17)
72 1/4 (46610) 8 1/2(215.9) x 8 1/2(215.9) 1 1/2” (38.1mm) magnesia
140,000(41.03)
81 (52260) 9(228.6) x 9(228.6) or more loose block.
154,000(45.13) 90 1/4 (58230) 9 1/2(241.3) x 9 1/2(241.3) insulation.
175,000(51.29) 100 (64520) 10(254) X 10(254)
210,000(61.55) 122 (78710) 11(279.4) X 11(279.4)
240,000(70.34) 144 (92900) 12(304.8) x 12(304.8)
250,000(76.2) 156 1/4 (100800) 12 1/2(317.5) X 12 1/2(317.5)
FIGURE 5
P265 ONLY
Input Floor Area Preferred Recommended Recommended
BTU/Hr. Sq. Inches Width and Minimum Minimum
(kW/Hr) (mm
2
) Length (mm) Wall Thickness Floor Construction
65,000 (19.05) 63 (40650) 7 (177.8) x 9 (228.6) 2 1/2” (63.5mm) insulating 2 1/2” (63.5mm) insulating
75,000 (21.98) 71 1/4 (45970) 7 1/2 (190.5) x 9 1/2 (241.3) firebrick plus back up firebrick plus 1 1/2” (38.1mm)
100,000 (29.31) 180 (116100) 7 1/2 (190.5) x 9 1/2 (241.3) of 1 1/2” (38.1mm) or magnesia
150,000 (43.96) 200 (129000) 12 (304.8) X 15 (381) more loose insulation. block.
200,000 (58.61) 220 (141900) 13 (330.2) x 17 (431.8)
FIGURE 5A
P265F
ONL
Y
Input Floor Area Preferred Recommended Recommended
BTU/Hr. Sq. Inches Width and Minimum Minimum
(kW/Hr.) (mm
2
) Length (mm) Wall Thickness Floor Construction
65,000 (19.05)
63 (40650)
7 (177.8) x 9 (228.6)
2 1/2” (63.5mm) insulating 2 1/2” (63.5mm) insulating
75,000 (21.98)
63 (40650)
7 (177.8) x 9 (228.6)
firebrick plus back up
firebrick plus 1 1/2” (38.1mm)
100,000 (29.31) 71 1/4 (45970) 7 1/2 (190.5) x 9 1/2 (241.3) of 1 1/2” (38.1mm) or magnesia
150,000 (43.96)
110 (70970)
10 (254) x 11 (297.4)
more loose insulation. block.
200,000 (58.61)
165 (106500)
11 (297.4) x 15 (381)
FIGURE 5B
