22
PARTS LIST - P265/P265F SERIES GAS BURNERS
62903-001 Control Box/Strap Assembly 1 • • • • • • • • •
60182-002 Power Cord Assembly 1 • • •
60186-004 Transformer - 24V 1 • • • • • • • • •
100986-002 Relay 1 • • • • • • • • •
62899 Control Box Cover 1 • • • • • • • • •
60172-002 Motor/Blower (inch end switch) 1 • • • • • • • • •
62901-001 Air Shutter - Stationary Position 1 • • • • • • • • •
61770-002 Air Shutter - Disc 1 • • • • • • • • •
62715-001 Air Tube/Housing Assembly 1 5” (127mm) 5”(127mm) 5”(127mm)
62715-003 Air Tube/Housing Assembly 1 8” (203.0mm) 8” (203.0mm) 8” (203.0mm)
62715-005 Air Tube/Housing Assembly 1 11”(279.4mm) 11”(279.4mm) 11”(279.4mm
62715-002 Air Tube/Housing Assembly 1 5” (127mm) 5” (127mm) 5” (127mm)
62715-004 Air Tube/Housing Assembly 1 8” (203.0mm) 8” (203.0mm) 8” (203.0mm)
62715-006 Air Tube/Housing Assembly 1 11”(279.4mm) 11”(279.4mm) 11”(279.4mm)
62715-007 Air Tube/Housing Assembly 1 • • •
21724-011 Adjustable Flange w/Gasket 1 • • • • • • • • •
100428-002 Flange Gasket 1 • • • • • • • • •
21760-011 Base Assembly 1 • • • • • • • • •
60270-002 Gas Valve - Standing Pilot 1 • • •
62246-004 Gas Valve - EP Pilot 1 • • •
62374-004 Gas Valve - Direct Spark (DI) 1 • • •
62898-001 Orifice Holder - 5” (127mm) Units 1 • • • • • • • • •
60249 Orifice Holder - 8” (203.2mm) Units 1 • • • •••
60250 Orifice Holder - 11” (279.4mm) Units 1•• •• ••
See Chart Orifices - Natural gas 1 • • • • • ••••
See Chart Orifices - LP gas 1 • •• ••••••
61455 Bulkhead Union 1 • • • • • • •
63432-001 Venturi - Less Fixed Flamespreader 1 • • •
60944 Venturi - Less Fixed Flamespreader 1 ••
61403 Venturi - With Fixed Flamespreader 1 • • • •
61637-003 Venturi - With Fixed Flamespreader 1 • •
60987 Thermocouple-5” (127mm) & 8” (203.2mm) Units 1 • • •
60280 Thermocouple - 11” (279.4) Units 1 • • •
63228-001 Pilot Burner 1 • • •
63062-001 Pilot Burner 1 • • •
60680-002 Pilot Orifice - Natural gas 1 • • • • • •
60680 Pilot Orifice - LP gas 1 • • • • • •
63210-001 Electrode Assembly - Piezo System 1 • • •
63212-001 Electrode Bracket - Piezo 1 • • •
62261-002 Electrode Assembly - DI 1 • • •
61818 Flamespreader 1 • • • • • • • • •
62243-003 Control - EP Pilot 1 • • •
101243-001 Control - Direct Spark (DI) 1 • • •
63213-001 Spark Generator - Pushbutton Piezo 1 • • •
63217-003 Ignitor Wire - Piezo Electrode 1 • • •
62947-003
Ignition Wire Assembly 1 • • • • • •
63375-001 Wire Set 1 • • •
62955-001 Burner Conversion Kit - Nat to LP 1 • • • • • •
62956-001 Burner Conversion Kit - LP to Nat 1 • • • • • •
Part No. Description
Qty
Req’d
P265 P265F P265F BB
P265 EP P265F EP P265F EP BB
P265 DI P265F DI
P265F DI BB
