PARTS LIST - P250AF SERIES GAS BURNERS
62903-001 Control Box/Strap Assembly 1 • • •
60182-002 Power Cord Assembly 1 •
60186-004 Transformer-24V 1 • • •
100986-002 Relay 1 • • •
62899 Control Box Cover 1 • • •
60172-002 Motor/Blower (inch end switch) 1 • • •
62901-001 Air Shutter - Stationary Portion 1 • • •
61770-002 Air Shutter - Disc 1 • • •
62715-003 Air Tube/Housing Assembly 1 • • •
63228-001 Pilot Burner 1 •
63062-001 Pilot Burner 1 •
62261 Electrode Assembly - DI 1 •
62261-002 Electrode Assembly - DI 1 •
See Chart Orifices - Natural gas 1 • • •
See Chart Orifices - LP gas 1 • • •
60680-002 Pilot Orifice - Natural gas 1 •
60680 Pilot Orifice - LP gas 1 • •
60987 Thermocouple 1 •
61818 Flamespreader 1 • • •
63213-001 Piezo Spark Generator 1 •
60270-002 Gas Valve - Standing Pilot 1 •
62246-004 Gas Valve - EP Pilot 1 •
62374-004 Gas Valve - Direct Spark (DI) 1 •
62243-003 Control - EP Pilot 1 •
101243-001 Control - Direct Spark (DI) 1 •
63212-001 Spark generator 1 •
62955-001 Burner Conversion Kit - Nat to LP 1 • •
62956-001 Burner Conversion Kit - LP to Nat 1 • •
63217-004 Ignitor Wire - Piezo Electrode 1•
62947-003 Ignition Wire Assembly 1 • •
63375-001 Wire Set 1 •
Part No. Description
No.
Req’d
P250AF
P250AF EP P250AF DI
